Drawbar Hitch System (Cat. 2) - Sparex Part No. S.144792

Enhance your agricultural or industrial equipment with the Drawbar Hitch System from Sparex. Designed for durability and efficiency, this hitch system features a robust construction with a pin diameter of 28mm and a hole diameter of 26mm. The hole centers are spaced at 83mm, ensuring compatibility with a variety of applications.

Product Specifications

• A (mm): 40
• Alternative to: 119469
• B (mm): 80
• Brand: Sparex
• C (mm): 862
• Category: 2
• Hole centres (mm): 83
• Hole Centres (ins): 3 17/64
• Hole Ø (ins): 1 1/32
• Hole Ø (mm): 26
• Linch Pin Ø (mm): 12
• Number of holes: 7
• Overall height (ins): 21 11/32
• Overall height (mm): 542
• Overall length (ins): 33 15/16
• Overall length (mm): 862
• Pin Ø (ins): 1 1/8
• Pin Ø (mm): 28
• Related products: 29230, 3342, 39
• Section (mm): 40x80
• Section (ins): 1 37/64 x 3 5/32
• Tariff Code: 7319909000
• Top Pin Diameter (mm): 19
• Top Pin Ø (ins): 3/4
• Working length (ins): 2 23/64
• Working length (mm): 60

Compatibility Information

This Drawbar Hitch System is designed for universal fitment and is not associated with any specific make or model.

Manufacturer Information

This product is not linked to any particular OEM part number, ensuring versatility across various applications.
